Specifications tables
Use the below list to jump to that specific table of specifications:
| Zezt code | Nominal Size DN (mm) | PN | SDR | length (m) | Material | colour |
|---|---|---|---|---|---|---|
| MM006572 | 16 | 10 | 17 | 400 | PE100 | yellow stripe |
| MM006176 | 25 | 10 | 17 | 200 | PE100 | yellow stripe |
| MM006816 | 25 | 10 | 17 | 100 | PE100 | yellow stripe |
| MM006402 | 63 | 10 | 17 | 12 | PE100 | yellow stripe |
| MM006341 | 63 | 10 | 17 | 100 | PE100 | yellow stripe |
| MM006342 | 125 | 10 | 17 | 12 | PE100 | yellow stripe |
| MM006308 | 200 | 10 | 17 | 12 | PE100 | yellow stripe |
| Zezt code | Nominal Size DN (mm) | PN | SDR | length (m) | Material | colour |
|---|---|---|---|---|---|---|
| MM005218 | 110 | 12.5 | 13.6 | 12 | PE100 | yellow stripe |
| MM005210 | 160 | 12.5 | 13.6 | 12 | PE100 | yellow stripe |
| Zezt code | Nominal Size DN (mm) | PN | SDR | length (m) | Material | colour |
|---|---|---|---|---|---|---|
| MM006011 | 20 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM004155 | 20 | 16 | 11 | 200 | PE100 | yellow stripe |
| MM006177 | 32 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM004156 | 32 | 16 | 11 | 150 | PE100 | yellow stripe |
| MM006581 | 40 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM006557 | 50 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM005970 | 63 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM006174P | 63 | 16 | 11 | 7 (capped) | PE100 | yellow stripe |
| MM006174 | 63 | 16 | 11 | 7 | PE100 | yellow stripe |
| MM005257 | 63 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM005742 | 63 | 16 | 11 | 50 | PE100 | yellow stripe |
| MM005967 | 63 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM006471 | 75 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006522 | 90 | 16 | 11 | 7 | PE100 | yellow stripe |
| MM006425 | 90 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM005212 | 90 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006524 | 110 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM005211 | 110 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006517 | 110 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM006523 | 110 | 16 | 11 | 110 | PE100 | yellow stripe |
| MM006424 | 125 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM005969 | 125 | 16 | 11 | 8 | PE100 | yellow stripe |
| MM005990 | 125 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006039 | 125 | 16 | 11 | 100 | PE100 | yellow stripe |
| MM006423 | 160 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM005255 | 160 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006175 | 180 | 16 | 11 | 8 | PE100 | yellow stripe |
| MM006214 | 180 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006680 | 180 | 16 | 11 | 20 | PE100 | yellow stripe |
| MM006422 | 200 | 16 | 11 | 6 | PE100 | yellow stripe |
| MM005506 | 200 | 16 | 11 | 12 | PE100 | yellow stripe |
| MM006687 | 225 | 16 | 11 | 12 | PE100 | yellow stripe |
| Zezt code | Nominal Size DN (mm) | PN | SDR | length (m) | Material | colour |
|---|---|---|---|---|---|---|
| MM006430 | 63 | 20 | 9 | 6 | PE100 | yellow stripe |
| MM006403 | 63 | 20 | 9 | 100 | PE100 | yellow stripe |
| MM006429 | 90 | 20 | 9 | 6 | PE100 | yellow stripe |
| MM006449 | 90 | 20 | 9 | 12 | PE100 | yellow stripe |
| MM006428 | 125 | 20 | 9 | 6 | PE100 | yellow stripe |
| MM006427 | 160 | 20 | 9 | 6 | PE100 | yellow stripe |
| MM006426 | 200 | 20 | 9 | 6 | PE100 | yellow stripe |
